The 0.199.059 is a SIT Controls IPI electronic ignition natural gas pilot assembly with high temperature orange wires. This pilot features an electronic intermitten pilot ignition.
This 0.199.059 natural gas pilot assembly is used on many different manufactures’ direct vent fireplaces including (but not limited to) Lennox IHP, Empire Comfort Systems, Travis Industries, and Napoleon.
Components of the 0199059 Pilot Assembly
Top-convertible side mount pilot has a primary air hole located below the bracket
Top-convertible 2-flame (IPI orientation) pilot hood
Injector and natural gas orifice
Spark Electrode and Cable for target style electrode with 0.125 in. female terminal.
Orange coated sensing electrode cable for sensing electrode with Teflon coated cable
Electrode Fixing Nut for attaching electrode to pilot bracket
Features a 1/8 in. diameter aluminum pilot tube
Specifications
Spark Electrode Cable:
Cable Length: 600 mm.
Female Terminal Length: 0.125 in.
Sensing Electrode Cable:
Cable Length: 610 mm.
Temperature Rating: 250°C
Connector Size: 3/16 in.
Cable Length: 610 mm.
Pilot Tube
Length: 24 in.
2B Valve Fixing Nut Size: 7/16 in. – 24 UNS
